99.95% pure tungsten tape roll low price tungsten foil from GETWICK

Model: W1

Item specifics

Product name: 99.95% Tungsten Foil for Electromagnetic Wave Shie

Key words: 99.95% Tungsten Foil

Purity: 99.95% min

Density: 19.3g/cm3

Melting point: 3260

Type: Tungsten foil

Shape: Rectangle

Application: Electromagnetic Wave Shield mateing

Material: Pure tungsten

Review

Description

99.95% pure tungsten tape roll low price tungsten foil from GETWICK

Grade: W1, W2, WAL1, WAL2, WAL3

Purity: W≥99.95%

Melting Point: 3410 DC

Boiling Point:5927 DC

Density: 18.5 - 19.3 g/cm3

Item: 99.95% high quality tungsten mirror foil price from GETWICK

Application:

1.Used for sapphire single crystal growth furnace;
2. Applied for quartz glass melting furnace;
3. Used for rare earth smelting furnace;
4. Used for sintering metal mold of high melting point;
5. Widely used in other following industries:
Ceramics and metallurgical industries, machinery processing and light dustries.

Features:

1.Low thermal expansion;

2. High density;
3. Good corrosion resistance
4. High strength;
5. Low resistivity;
6.The surface roughness of tooled crucibles does not exceed Rz 6.3;
7.The use temperature below 2450ºC in vacuum or deoxidize atmosphere.
8.Manufactured based on customers' requirement.

Surface: shiny, alkaline washed, satin, or as-rolled condition; dependent upon thickness and width

parameters.

Normal specification we can provide:

Tungsten Plate/Sheet /Foil
Thickness(min) mm	Width(max) mm	Length(max) mm
0.05	150	500
0.06~0.09	250	500
0.1	300	500
0.12	320	550
0.15	350	600
0.2~0.6	400	600
0.7~0.9	400	800
1~2	450	800
2~10	450	600
10~15	450	500
15~25	300	500

We also provide other parameters of tungsten foils according to customers' requirements.

Main Comp.W≥99.95
Other Content≤	Fe	0.0026	Al	0.0006	Si	0.001
	Ca	0.001	Ni	0.0009	O	0.0018
	Cu	0.0005	N	0.0015	Pb	0.0001
	Sn	0.0001	Sb	0.001	As	0.001
	Cd	0.0001	Mg	0.0006	C	0.002
	Bi	0.0001	Mo	0.003
